ToughTek P30X
ToughTek P30X System
25M040
ToughTek P30X
ToughTek P30X System
25M040
The simple technology of a rotor stator pump is perfect for contractors who are looking for a basic pump that is easy to clean and service. The P30X has a large 60-gallon (227 L) hopper and offers superior performance from a rotor stator pump.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The simple technology of a rotor stator pump is perfect for contractors who are looking for a basic pump that is easy to clean and service. The P30X has a large 60-gallon (227 L) hopper and offers superior performance from a rotor stator pump.
For medium to large projects
- Easy to use, easy to move
- Variable pump output lets you adjust material flow
- Optional remote control operation
- Flow rate: 10 gpm (38 lpm)
- Output (underlayment): 200 bags per hour (based on 50-lb/22.6 kg bags)
- Pumping distance: 100 feet + (30 m)
- Pumping height: 60 feet (18 m)
- Reversible pump direction
- Hopper capacity: 60 Gal (227.1 L)
- Power requirements: 230V, 30A, 1-ph
Specifications & Documents
Technical Specifications
Convert to Metric| Compatible Material | Repair Mortar, Stucco, EIFS, Self-Leveling Underlayment, Cementitious Fireproofing |
|---|---|
| Fluid Inlet Size (in) | 3.8 |
| Fluid Outlet Size (in) | 1.5 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | NPT |
| Maximum Flow Rate (GPM) | 16.6 |
| Maximum Working Pressure (MPa) | 2.1 |
| Maximum Working Pressure (psi) | 300 |
| Motor Type | Electric |
| Overall Height (ft) | 2.58 |
| Overall Height (in) | 31 |
| Overall Length (ft) | 6.58 |
| Overall Length (in) | 79 |
| Overall Width (ft) | 2.83 |
| Overall Width (in) | 34 |
| Power Rating (HP) | 5.4 |
| Power Rating (W) | 4026.8 |
| Power Rating (kW) | 4.03 |
| Type | Electric Rotor Stator Pump |
| Weight (lb) | 420 |
| Wetted Parts | Tool Steel, Painted Steel, Plated Steel, PORON |
| Compatible Material | Repair Mortar, Stucco, EIFS, Self-Leveling Underlayment, Cementitious Fireproofing |
| Fluid Inlet Size (cm) | 9.7 |
| Fluid Inlet Size (mm) | 96.5200 |
| Fluid Outlet Size (cm) | 3.81 |
| Fluid Outlet Size (mm) | 38.1 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | NPT |
| Maximum Working Pressure (MPa) | 2.1 |
| Maximum Working Pressure (bar) | 20.7 |
| Maximum Working Pressure (kPa) | 2070 |
| Motor Type | Electric |
| Overall Height (cm) | 78.74 |
| Overall Height (m) | 0.79 |
| Overall Height (mm) | 787.4 |
| Overall Length (cm) | 201 |
| Overall Length (m) | 2 |
| Overall Length (mm) | 2007 |
| Overall Width (cm) | 86.36 |
| Overall Width (m) | 0.86 |
| Overall Width (mm) | 863.60 |
| Power Rating (HP) | 5.4 |
| Power Rating (W) | 4026.8 |
| Power Rating (kW) | 4.03 |
| Type | Electric Rotor Stator Pump |
| Weight (kg) | 190.5 |
| Wetted Parts | Tool Steel, Painted Steel, Plated Steel, PORON |
Product Manuals
