ToughTek MP20

ToughTek MP20 Bare Mixing Pump System, 230V, 16A, 1Ph, 50Hz

25M061

ToughTek MP20

ToughTek MP20 Bare Mixing Pump System, 230V, 16A, 1Ph, 50Hz

25M061

With its ability to mix and pump, this all-in-one compact machine is the ideal solution for contractors looking to make the switch from manually applying self-leveling underlayment. The MP20 can deliver up to 100 bags per hour allowing contractors to get jobs done faster.

Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure

With its ability to mix and pump, this all-in-one compact machine is the ideal solution for contractors looking to make the switch from manually applying self-leveling underlayment. The MP20 can deliver up to 100 bags per hour allowing contractors to get jobs done faster.

Ideal for self-leveling underlayment, non-shrink grout and pre-blended toppings

  • Compact, easy to maneuver
  • Easy to operate with variable speed control
  • 425 psi (29 bar) pumping pressure
  • Vertical pumping distance: 60 feet (18 m)
  • Horizontal pumping distance: 200 feet (61 m)
  • Rugged hopper with bag breaker – holds six 50-lb (23 kg) bags
  • Power MP20: 230V, 30A, 1-ph
  • Output MP20: up to 25 lpm (50 cu ft/hr)

Specifications & Documents

Technical Specifications

Convert to Metric
Hopper Capacity (gal) 37.4
Maximum Input Amperage (A) 16
Phase 1
Type Continuous Mixer
Voltage (V ac) 240
Weight (lb) 430
Hopper Capacity (L) 141.6
Maximum Input Amperage (A) 16
Phase 1
Type Continuous Mixer
Voltage (V ac) 240
Weight (kg) 195
