EcoQuip 2 EQs Dual Line

EcoQuip 2 EQs Dual Line No Water Tank Pneumatic Hose Package

Part Number: 282952

product image product image product image product image

EcoQuip 2 EQs Dual Line

EcoQuip 2 EQs Dual Line No Water Tank Pneumatic Hose Package

Part Number: 282952

Designed to be transported easily around jobsites with accessible forklift pockets as well as lifting hooks for aerial mobility, Graco’s EcoQuip EQs Dual Line is a compact skid that is perfect for locations with a pressurized water source. This Vapor Abrasive blaster features two outlets and a large... More Info

Features

Product Brochure
Designed to be transported easily around jobsites with accessible forklift pockets as well as lifting hooks for aerial mobility, Graco’s EcoQuip EQs Dual Line is a compact skid that is perfect for locations with a pressurized water source. This Vapor Abrasive blaster features two outlets and a large pressure pot capable of blasting up to four hours with two blasters at once. Get your project up and running quickly with this high production machine.
  • One 12 cubic ft (340 L) blast pot - holds approximately (30) 55 lb (25 kg) bags of media
  • Accessible forklift pockets and lifting hooks for ease of transportation around a jobsite
  • Single control box with simple user interface for easy control
  • Fully coated frame that has a durable, welded design for robust environments
  • Unrestricted fill opening allowing for 2x faster loading than regular skid model

Specifications & Documents

Technical Specifications

Convert to Metric
Abrasive Capacity (lb) 1400
Air Inlet Size (in) 2
Air Inlet Thread Type NPT
Blast Hose Coupler 1 Material Brass
Blast Hose Coupler 1 Type Nozzle Holder
Blast Hose Inside Diameter (in) 1-1/4
Blast Hose Length (ft) 50
Compatible Abrasives Garnet, Crushed Glass, Coal Slag, Glass Beads, Plastic, Walnut Shells, Baking Soda
Configuration Skid
Control Type Pneumatic
Dry Weight (lb) 1400
Enclosure Material Coated
Frame Material Coated
Frame Type Skid/Crash Frame
Maximum Operating Temperature (°F) 110
Maximum Working Pressure (MPa) 1
Maximum Working Pressure (psi) 150
Minimum Operating Temperature (°F) 35
Model EcoQuip 2
Nozzle Type #8 High Performance
Pot Capacity (ft³) 12
Pot Capacity (gal) 90
Pot Finish/Coating A-Coat/Powder
Recommended Compressor Size (CFM) 750-1600
Series EQs Dual Line
Type Abrasive Blast System
Unit Type High Production Unit
Water Tank Material Polyethylene
Water Tank Type No Water Tank
Water Tank Volume (gal) 115
Wet Weight (lb) 4200
Air Inlet Size (cm) 5.08
Air Inlet Size (in) 2
Air Inlet Size (mm) 50.8
Air Inlet Thread Type NPT
Blast Hose Coupler 1 Material Brass
Blast Hose Coupler 1 Type Nozzle Holder
Blast Hose Inside Diameter (in) 1-1/4
Blast Hose Inside Diameter (mm) 31.75
Blast Hose Length (m) 15
Compatible Abrasives Garnet, Crushed Glass, Coal Slag, Glass Beads, Plastic, Walnut Shells, Baking Soda
Configuration Skid
Control Type Pneumatic
Enclosure Material Coated
Frame Material Coated
Frame Type Skid/Crash Frame
Maximum Operating Temperature (°C) 43.3
Maximum Working Pressure (MPa) 1
Maximum Working Pressure (bar) 10.3
Maximum Working Pressure (kPa) 1030
Maximum Working Pressure (kg/cm²) 10.55
Maximum Working Pressure (psi) 150
Minimum Operating Temperature (°C) 1.6
Model EcoQuip 2
Nozzle Type #8 High Performance
Pot Capacity (L) 340
Pot Finish/Coating A-Coat/Powder
Series EQs Dual Line
Type Abrasive Blast System
Unit Type High Production Unit
Water Tank Material Polyethylene
Water Tank Type No Water Tank

Repair Parts

Part No. Description
106148 Air Filter - 3/8 in NPT with 20 Micron Filter
25P031 KIT,PUMP,WATER,10:1,SST
24V671 LOWER,DISPLACEMENT,SST
