RAC IV SwitchTip

RAC IV SwitchTip 313

221313

The Reverse-A-Clean (RAC) 313 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 313 SwitchTip has a 0.013 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.
$25.99
USD MSRP

Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The Reverse-A-Clean (RAC) 313 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 313 SwitchTip has a 0.013 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.
  • Reverse-A-Clean (RAC) IV SwitchTip

    • Select different-sized tips based on the material used
    • Reversible — quickly clear tip plugs with a twist
    • Easily installs on Gun without tools

Specifications

Technical Specifications

Convert to Metric
Compatible Material Stains, Oil-Based Paint, Lacquer, Polyurethane
For Use With Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (in) 8
Maximum Flow Rate (GPM) .18
Maximum Flow Rate (L/min) .69
Maximum Working Pressure (psi) 4050
Minimum Fan Width (in) 6
Orifice Diameter (in) 0.013
Type Spray Tip
Compatible Material Stains, Oil-Based Paint, Lacquer, Polyurethane
For Use With Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (mm) 203
Maximum Flow Rate (GPM) .18
Maximum Flow Rate (L/min) .69
Maximum Working Pressure (bar) 280
Maximum Working Pressure (kPa) 28000
Maximum Working Pressure (kg/cm²) 286
Minimum Fan Width (mm) 152
Orifice Diameter (cm) 0.0330
Orifice Diameter (mm) 0.3302
Type Spray Tip

What's Included

Part No. Description Qty Unit
185557 GASKET 1 ea
188357 RETAINER, TIP 1 ea
403296 CARD, BLISTER RAC IV 1 ea
188358 HANDLE, CYLINDER 1 ea
