RAC IV SwitchTip

RAC IV SwitchTip 315

221315

221315_RAC_IV_Spray_Tip_Main
Rac 4 Tip

RAC IV SwitchTip

RAC IV SwitchTip 315

221315

The Reverse-A-Clean (RAC) 315 RAC IV SwitchTip is designed for narrow surfaces and materials like solid color stains, enamels, primers, interior paints, paint + primers, and exterior paints. The 315 SwitchTip has a 0.015 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily cl... More Info
$25.99
USD MSRP

Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The Reverse-A-Clean (RAC) 315 RAC IV SwitchTip is designed for narrow surfaces and materials like solid color stains, enamels, primers, interior paints, paint + primers, and exterior paints. The 315 SwitchTip has a 0.015 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs.
  • Reverse-A-Clean (RAC) IV SwitchTip

    • Select different-sized tips based on the material used
    • Reversible — quickly clear tip plugs with a twist
    • Easily installs on Gun without tools

Specifications

Technical Specifications

Convert to Metric
Compatible Material Stains, Enamel, Primer, Interior and Exterior Paint
For Use With Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (in) 8
Maximum Flow Rate (GPM) .24
Maximum Flow Rate (L/min) .91
Maximum Working Pressure (psi) 4050
Minimum Fan Width (in) 6
Orifice Diameter (in) 0.015
Type Spray Tip
Compatible Material Stains, Enamel, Primer, Interior and Exterior Paint
For Use With Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (mm) 203
Maximum Flow Rate (GPM) .24
Maximum Flow Rate (L/min) .91
Maximum Working Pressure (bar) 280
Maximum Working Pressure (kPa) 28000
Maximum Working Pressure (kg/cm²) 286
Minimum Fan Width (mm) 152
Orifice Diameter (cm) 0.0381
Orifice Diameter (mm) 0.3810
Type Spray Tip

What's Included

Part No. Description Qty Unit
188358 HANDLE, CYLINDER 1 ea
188357 RETAINER, TIP 1 ea
403296 CARD, BLISTER RAC IV 1 ea
185557 GASKET 1 ea
