RAC IV SwitchTip

RAC IV SwitchTip 617

221617

The Reverse-A-Clean (RAC) 617 RAC IV SwitchTip is designed for wide surfaces and materials like enamels, primers, interior paints, paint + primers, and exterior paints. The 617 SwitchTip has a 0.017 inch orifice and produces a 12 to 14 inch fan. Reverse the SwitchTip to easily clear clogs.
$25.99
USD MSRP

Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The Reverse-A-Clean (RAC) 617 RAC IV SwitchTip is designed for wide surfaces and materials like enamels, primers, interior paints, paint + primers, and exterior paints. The 617 SwitchTip has a 0.017 inch orifice and produces a 12 to 14 inch fan. Reverse the SwitchTip to easily clear clogs.
  • Reverse-A-Clean (RAC) IV SwitchTip

    • Select different-sized tips based on the material used
    • Reversible — quickly clear tip plugs with a twist
    • Easily installs on Gun without tools

Specifications

Technical Specifications

Convert to Metric
Compatible Material High Solids Epoxy Primer, High Solids Epoxy Coating, Architectural Latex Emulsion Paint
For Use With X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (in) 14
Maximum Flow Rate (GPM) .31
Maximum Flow Rate (L/min) 1.17
Maximum Working Pressure (psi) 4050
Minimum Fan Width (in) 12
Orifice Diameter (in) 0.017
Pattern Size (in) 12 to 14
Tip Type Airless
Type Spray Tip
Compatible Material High Solids Epoxy Primer, High Solids Epoxy Coating, Architectural Latex Emulsion Paint
For Use With X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart
Maximum Fan Width (mm) 356
Maximum Flow Rate (GPM) .31
Maximum Flow Rate (L/min) 1.17
Maximum Working Pressure (bar) 280
Maximum Working Pressure (kPa) 28000
Maximum Working Pressure (kg/cm²) 286
Minimum Fan Width (mm) 305
Orifice Diameter (cm) 0.0432
Orifice Diameter (mm) 0.4318
Tip Type Airless
Type Spray Tip

What's Included

Part No. Description Qty Unit
188357 RETAINER, TIP 1 ea
188358 HANDLE, CYLINDER 1 ea
185557 GASKET 1 ea
403296 CARD, BLISTER RAC IV 1 ea
