SD 5
SD™ 5 Series 230 Volt Cord Reel - No Accessory, Cord Only - 15 m, 10 Amp Cord- Black
Part Number: 24Y874

SD 5
SD™ 5 Series 230 Volt Cord Reel - No Accessory, Cord Only - 15 m, 10 Amp Cord- Black
Part Number: 24Y874
Organize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product BrochureOrganize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.
- Heavy-duty steel construction, SD Series size 5.
- 15 meter cord and features a 5 foot (1.5 meter) lead-in cable.
- Cord only, no accessory
Adjustable Arm - Easily change the arm position to fit more applications. Works on walls, ceilings or bench mounts.
Heavy-Duty Pedestal - High-strength steel construction with rolled edges and ribbed stress points that won't flex or twist.
Specifications & Documents
Technical Specifications
Convert to MetricCord Length (ft) | 50 |
---|---|
Includes | Cord Only |
Insulation Type | H05RR-F |
Maximum Current (A) | 10 |
Maximum Operating Temperature (°F) | 122 |
Model | SD |
Overall Height (in) | 14.8 |
Overall Length (in) | 13.84 |
Overall Width (in) | 4.7 |
Reel Color | Black |
Series | 5 |
Sound Power Level (dB(A)) | 87 |
Sound Pressure Level (dB) | 80 |
Type | Cord Reel |
Voltage (V ac) | 230 |
Weight (lb) | 30.6 |
Cord Length (m) | 15 |
Includes | Cord Only |
Insulation Type | H05RR-F |
Maximum Current (A) | 10 |
Maximum Operating Temperature (°C) | 50 |
Model | SD |
Overall Height (cm) | 37.59 |
Overall Height (mm) | 375.9 |
Overall Length (cm) | 35.2 |
Overall Length (mm) | 352 |
Overall Width (cm) | 11.938 |
Overall Width (mm) | 119.38 |
Reel Color | Black |
Series | 5 |
Sound Power Level (dB(A)) | 87 |
Sound Pressure Level (dB) | 80 |
Type | Cord Reel |
Voltage (V ac) | 230 |
Weight (kg) | 13.9 |
Wire Gauge Size (mm²) | 1,5 |
