GCI 150
GCI™ Series 150 Grease Injector
Part Number: 134250
GCI 150
GCI™ Series 150 Grease Injector
Part Number: 134250
Graco quick-exchange cartridge injectors are easy to handle, can be serviced in one minute or less and eliminate the need to disconnect lines when replacing. Numerous injector replacements on a machine can be completed in minutes instead of hours, leaving service technicians with more time to focus ...
More Info
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Graco quick-exchange cartridge injectors are easy to handle, can be serviced in one minute or less and eliminate the need to disconnect lines when replacing. Numerous injector replacements on a machine can be completed in minutes instead of hours, leaving service technicians with more time to focus on other equipment issues.
For use with GCI Manifolds in mining, construction, off-road/on-road mobile equipment and other single-line parallel automatic lubrication applications.
- Quick Exchange Injectors — Injector replacements take seconds rather than minutes using either a 24 mm or 15/16 in. socket – without the need to remove any lubrication lines.
- High-Visibility Indicator Pin — 360-degree view of coloured indicator pin makes trouble shooting a breeze.
- Quality + Durability — The new streamlined cartridge injector leverages state-of-the-art manufacturing processes to deliver greater life.
- Lower replacement injector costs compared to similar class legacy injector technologies (-1, -1X, -V).
Specifications & Documents
Technical Specifications
Convert to Imperial| Application | In-Plant Machinery, Off-Road Equipment |
|---|---|
| Compatible Material | Grease |
| Compatible Metering Device | Single Line Parallel |
| Cycle Indicator | Visual |
| For Use With | Single Line Parallel Automatic Lubrication Systems |
| Maximum NLGI Grade | #2 |
| Maximum Operating Pressure (psi) | 5000 |
| Maximum Working Pressure (MPa) | 34.5 |
| Maximum Working Pressure (psi) | 5000 |
| Model | GCI |
| Series | 150 |
| Suggested Operating Pressure (psi) | 2500 |
| Type | Grease Injector |
| Wetted Material | Carbon Steel, Nitrile Rubber, Aluminium |
| Application | In-Plant Machinery, Off-Road Equipment |
| Compatible Material | Grease |
| Compatible Metering Device | Single Line Parallel |
| Cycle Indicator | Visual |
| For Use With | Single Line Parallel Automatic Lubrication Systems |
| Maximum NLGI Grade | #2 |
| Maximum Operating Pressure (psi) | 5000 |
| Maximum Working Pressure (MPa) | 34.5 |
| Maximum Working Pressure (bar) | 345 |
| Maximum Working Pressure (psi) | 5000 |
| Model | GCI |
| Series | 150 |
| Suggested Operating Pressure (psi) | 2500 |
| Type | Grease Injector |
| Wetted Material | Carbon Steel, Nitrile Rubber, Aluminium |
