Electric Dyna-Star® Custom Tank Injector Kit – 24 VDC HP pump, Vent Valve with Tube-in-Tube for 180 kg (400 lb) Reservoir
Part Number: 77X013
Image is for illustrative purposes only.
Dyna-Star
Electric Dyna-Star® Custom Tank Injector Kit – 24 VDC HP pump, Vent Valve with Tube-in-Tube for 180 kg (400 lb) Reservoir
Part Number: 77X013
Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.
Electric pumps for heavy duty automatic lubrication and transfer systems.
- Graco Advantage Drive™ – heavy duty gear drive – lubed for life
- Tube-in-tube vent and fill path – convert drum to injector system instantly
- Vent valve mounted directly to pump – no more brackets or extra hoses and pipes
- Motor control – speed and AMP control
- Cold weather performance (-40°C)
- More efficient seal replacement
Specifications & Documents
Technical Specifications
Convert to Imperial| Air Inlet Size (in) | 1/4 |
|---|---|
| Air Inlet Thread Type | NPT |
| Application | In-Plant Machinery, Off-Road Equipment |
| Compatible Material | Oil & Grease |
| Compatible Metering Device | Single Line Parallel |
| Fluid Outlet Size (in) | 0.375 |
| Fluid Outlet Thread Type | NPT |
| IP Rating | IP69K |
| Includes | HP Pump, Vent Valve, 180 kg (400 lb) Reservoir |
| Maximum Working Pressure (MPa) | 34.5 |
| Maximum Working Pressure (psi) | 3500 |
| Minimum cST Grade (cST) | 40 |
| Model | Dyna-Star |
| Overall Height (in) | 44.3 |
| Overall Width (in) | 11 |
| Power Connection Type | M23 |
| Power Type | Electric |
| Reservoir Size (lb) | 400 |
| Type | Electric Piston Pump |
| Voltage (V DC) | 24 |
| Weight (lb) | 60 |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Size (mm) | 6.35 |
| Air Inlet Thread Type | NPT |
| Application | In-Plant Machinery, Off-Road Equipment |
| Compatible Material | Oil & Grease |
| Compatible Metering Device | Single Line Parallel |
| Fluid Outlet Size (in) | 0.375 |
| Fluid Outlet Size (mm) | 9.5250 |
| Fluid Outlet Thread Type | NPT |
| IP Rating | IP69K |
| Includes | HP Pump, Vent Valve, 180 kg (400 lb) Reservoir |
| Maximum Working Pressure (MPa) | 34.5 |
| Maximum Working Pressure (bar) | 345 |
| Maximum Working Pressure (kPa) | 34500 |
| Maximum Working Pressure (psi) | 3500 |
| Minimum cST Grade (cST) | 40 |
| Model | Dyna-Star |
| Overall Height (cm) | 112.5 |
| Overall Height (mm) | 1125 |
| Overall Width (cm) | 27.9 |
| Overall Width (mm) | 279 |
| Power Connection Type | M23 |
| Power Type | Electric |
| Type | Electric Piston Pump |
| Voltage (V DC) | 24 |
| Weight (kg) | 27.22 |
