Fast-Ball 100
Fast-Ball 100 55 gallon drum, universal pump, steel tube
Part Number: 279037
Image is for illustrative purposes only.
Image is for illustrative purposes only.
Image is for illustrative purposes only.
Fast-Ball 100
Fast-Ball 100 55 gallon drum, universal pump, steel tube
Part Number: 279037
Redesigned for enhanced quality, durability and reliability, the Fast-Ball 100 air-operated piston pump is easy to install, easy to operate, and the simple design allows for efficient serviceability when necessary to minimise downtime and keep your operations running.
Features
Product Brochure
Redesigned for enhanced quality, durability and reliability, the Fast-Ball 100 air-operated piston pump is easy to install, easy to operate, and the simple design allows for efficient serviceability when necessary to minimise downtime and keep your operations running.
Ideal for low-volume transfer of petroleum and synthetic-based oils with a continuous duty flow rate of up to 5 gpm (19lpm).
- In-line design with fewer parts for less pump wear
- The double-acting pump provides reliable fluid flow
- The differential air motor ensures smooth pumping
- The pump comes with a 34.5" downtube designed to fit a 55 gallon drum
Specifications & Documents
Technical Specifications
Convert to Imperial| Air Inlet Size (in) | 1/4 |
|---|---|
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Compatible Material | ATF, Gear Lube, Oil |
| Cycles per Gallon | 31 |
| Fluid Inlet Size (in) | 1 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 0.75 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Continuous Cycle Rate (CPM) | 170 |
| Maximum Working Pressure (psi) | 150 |
| Model | Fast-Ball |
| Power Type | Pneumatic |
| Pump Ratio | 1:1 |
| Series | 100 |
| Sound Power Level (dB(A)) | 78 |
| Sound Pressure Level (dB(A)) | 73.2 |
| Type | Pneumatic piston pump |
| Weight (lb) | 9.8 |
| Wetted Material | Aluminium, NBR, Nickel-Plated Aluminium, Nitrile, Polyurethane, Steel, Zinc-Plated Carbon Steel |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Compatible Material | ATF, Gear Lube, Oil |
| Cycles per Gallon | 31 |
| Fluid Inlet Size (in) | 1 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 0.75 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Continuous Cycle Rate (CPM) | 170 |
| Maximum Working Pressure (psi) | 150 |
| Model | Fast-Ball |
| Power Type | Pneumatic |
| Pump Ratio | 1:1 |
| Series | 100 |
| Sound Power Level (dB(A)) | 78 |
| Sound Pressure Level (dB(A)) | 73.2 |
| Type | Pneumatic piston pump |
| Wetted Material | Aluminium, NBR, Nickel-Plated Aluminium, Nitrile, Polyurethane, Steel, Zinc-Plated Carbon Steel |
