RAC IV SwitchTip
RAC IV SwitchTip 513
Part Number: 221513
Rac 4 Tip
RAC IV SwitchTip
RAC IV SwitchTip 513
Part Number: 221513
The Reverse-A-Clean (RAC) 513 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 513 SwitchTip has a 0.013 inch orifice and produces a 10 to 12 inch fan. Reverse the SwitchTip to easily clear clogs.
$25.99
USD MSRP
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The Reverse-A-Clean (RAC) 513 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 513 SwitchTip has a 0.013 inch orifice and produces a 10 to 12 inch fan. Reverse the SwitchTip to easily clear clogs.
Reverse-A-Clean (RAC) IV SwitchTip
- Select different-sized tips based on the material used
- Reversible — quickly clear tip plugs with a twist
- Easily installs on Gun without tools
Specifications & Documents
Technical Specifications
Convert to Metric| Compatible Material | Architectural Latex Emulsion Paint, Epoxy Primer, High Solids Polyurethane Coating, High Solids Epoxy Coating, High Solids Epoxy Primer |
|---|---|
| For Use With | Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart |
| Maximum Fan Width (in) | 12 |
| Maximum Flow Rate (GPM) | 0.18 |
| Maximum Working Pressure (psi) | 4050 |
| Minimum Fan Width (in) | 10 |
| Model | RAC IV |
| Orifice Diameter (in) | 0.013 |
| Pattern Size (in) | 10 to 12 |
| Series | SwitchTip |
| Tip Type | Airless |
| Type | Spray Tip |
| Compatible Material | Architectural Latex Emulsion Paint, Epoxy Primer, High Solids Polyurethane Coating, High Solids Epoxy Coating, High Solids Epoxy Primer |
| For Use With | Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart |
| Maximum Fan Width (cm) | 30.5 |
| Maximum Fan Width (in) | 12 |
| Maximum Fan Width (mm) | 305 |
| Maximum Flow Rate (L/min) | 0.68 |
| Maximum Working Pressure (bar) | 280 |
| Maximum Working Pressure (kPa) | 28000 |
| Maximum Working Pressure (psi) | 4050 |
| Minimum Fan Width (mm) | 254 |
| Model | RAC IV |
| Orifice Diameter (cm) | 0.033 |
| Orifice Diameter (in) | 0.013 |
| Orifice Diameter (mm) | 0.3302 |
| Pattern Size (mm) | 254 to 304.8 |
| Series | SwitchTip |
| Tip Type | Airless |
| Type | Spray Tip |
