Modu-Flo AL-50

Modu-Flo® AL-50 Pneumatic Pump without Reservoir

Part Number: 563308

product image
Image is for illustrative purposes only.

Modu-Flo AL-50

Modu-Flo® AL-50 Pneumatic Pump without Reservoir

Part Number: 563308

Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure

Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

  • Easy to standardize on components and reduce inventory
  • Adjustable pump output for fast, convenient customizing
  • Lubriquip part number 521-000-041

Specifications & Documents

Technical Specifications

Convert to Metric
Application In-Plant Machinery
Compatible Material Oil, Grease
Compatible Metering Device Series Progressive
Maximum Air Inlet Pressure (psi) 150
Maximum Cycle Rate (CPM) 30
Maximum Fluid Output Pressure (psi) 3500
Maximum NLGI Grade #2
Maximum Working Pressure (MPa) 31
Maximum Working Pressure (psi) 3000
Model Modu-Flo
Overall Depth (in) 3.188
Overall Height (in) 3.188
Overall Width (in) 12.812
Power Type Pneumatic
Series AL-50
Type Pneumatic Piston Pump
Application In-Plant Machinery
Compatible Material Oil, Grease
Compatible Metering Device Series Progressive
Maximum Air Inlet Pressure (bar) 10.34
Maximum Air Inlet Pressure (kPa) 1034
Maximum Air Inlet Pressure (psi) 150
Maximum Cycle Rate (CPM) 30
Maximum Fluid Output Pressure (bar) 241
Maximum Fluid Output Pressure (psi) 3500
Maximum NLGI Grade #2
Maximum Working Pressure (MPa) 31
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20680
Maximum Working Pressure (psi) 3000
Model Modu-Flo
Overall Depth (cm) 8.1
Overall Depth (mm) 81
Overall Height (cm) 8.1
Overall Height (mm) 81
Overall Width (cm) 32.5
Overall Width (mm) 325
Power Type Pneumatic
Series AL-50
Type Pneumatic Piston Pump
