Lube Master
Lube Master® Electric Pump, 20 lb. (9.06 kg) Grease Metal Reservoir, 60:1 Floor Mount, 230/460V, 1/2 HP, 3 PH, 60 Hz, 1725 RPM, LL
Part Number: LM8534
Image is for illustrative purposes only.
Image is for illustrative purposes only.
Lube Master
Lube Master® Electric Pump, 20 lb. (9.06 kg) Grease Metal Reservoir, 60:1 Floor Mount, 230/460V, 1/2 HP, 3 PH, 60 Hz, 1725 RPM, LL
Part Number: LM8534
The Lube Master is a rugged pump package designed for demanding applications. The adjustable output and anti-friction drive bearings make it both reliable and efficient. Rugged cast iron main body and heavy-duty internal components deliver consistent performance in harsh applications.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The Lube Master is a rugged pump package designed for demanding applications. The adjustable output and anti-friction drive bearings make it both reliable and efficient. Rugged cast iron main body and heavy-duty internal components deliver consistent performance in harsh applications.
Built For Severe-Duty Environments.
- Adjustable output
- Broad output range
- Simplified construction
- Hardened steel piston in steel sleeve
- Soft-seat outlet check valve
- Modular components
- Driven by an electric motor (gear drive)
Specifications & Documents
Technical Specifications
Convert to Metric| Application | In-Plant Machinery |
|---|---|
| Compatible Material | Grease |
| Compatible Metering Device | Series Progressive |
| Fluid Outlet Size (in) | 0.25 |
| Fluid Outlet Thread Type | NPSF |
| Material | Metal |
| Maximum Cycle Rate (strokes/min) | 175 |
| Maximum Flow Rate (ci/min) | 8.62 |
| Maximum Fluid Output Pressure (psi) | 5000 |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (MPa) | 34 |
| Maximum Working Pressure (psi) | 5000 |
| Minimum Cycle Rate (strokes/min) | 1 |
| Minimum Flow Rate (ci/min) | 0.01 |
| Model | Lube Master |
| Overall Depth (in) | 10.25 |
| Overall Height (in) | 26.56 |
| Overall Width (in) | 7.812 |
| Power Type | Electric |
| Reservoir Size (lb) | 20 |
| Type | Electric Piston Pump |
| Voltage (V ac) | 230/460 |
| Application | In-Plant Machinery |
| Compatible Material | Grease |
| Compatible Metering Device | Series Progressive |
| Fluid Outlet Size (in) | 0.25 |
| Fluid Outlet Size (mm) | 6.3500 |
| Fluid Outlet Thread Type | NPSF |
| Material | Metal |
| Maximum Cycle Rate (strokes/min) | 175 |
| Maximum Fluid Output Pressure (bar) | 345 |
| Maximum Fluid Output Pressure (psi) | 5000 |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (MPa) | 34 |
| Maximum Working Pressure (bar) | 340 |
| Maximum Working Pressure (kPa) | 34000 |
| Maximum Working Pressure (psi) | 5000 |
| Minimum Cycle Rate (strokes/min) | 1 |
| Model | Lube Master |
| Overall Depth (cm) | 26 |
| Overall Depth (mm) | 260 |
| Overall Height (cm) | 67.5 |
| Overall Height (mm) | 675 |
| Overall Width (cm) | 19.8 |
| Overall Width (mm) | 198 |
| Power Type | Electric |
| Type | Electric Piston Pump |
| Voltage (V ac) | 230/460 |
