Fast-Ball 100
Fast-Ball 100 Universal Pump
Part Number: 279035
Image is for illustrative purposes only.
Image is for illustrative purposes only.
Image is for illustrative purposes only.
Fast-Ball 100
Fast-Ball 100 Universal Pump
Part Number: 279035
Redesigned for enhanced quality, durability and reliability, the Fast-Ball 100 air-operated piston pump is easy to install, easy to operate, and simple design allows for efficient serviceability when necessary to minimize downtime and keep your operations running.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Redesigned for enhanced quality, durability and reliability, the Fast-Ball 100 air-operated piston pump is easy to install, easy to operate, and simple design allows for efficient serviceability when necessary to minimize downtime and keep your operations running.
Ideal for low-volume transfer of petroleum and synthetic-based oils with a continuous duty flow rate of up to 5 gpm (19lpm).
- In-line design with fewer parts for less pump wear
- Double-acting pump provides reliable fluid flow
- Differential air motor ensures smooth pumping
- Pump can be upfitted with downtube to fit a drum or bulk tank
Specifications & Documents
Technical Specifications
Convert to Metric| Air Inlet Size (in) | 1/4 |
|---|---|
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Fast Lube and Service Centers |
| Compatible Material | ATF, Gear Lube, Oil |
| Construction | Aluminum, NBR, Nickel-Plated Aluminum, Nitrile, Polyurethane, Steel, Zinc-Plated Carbon Steel |
| Cycles Per Gallon | 31 |
| Fluid Inlet Size (in) | 1 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 0.75 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Continuous Cycle Rate (CPM) | 170 |
| Maximum Working Pressure (psi) | 150 |
| Model | Fast-Ball |
| Power Type | Pneumatic |
| Pump Ratio | 1:1 |
| Series | 100 |
| Sound Pressure Level (dB(A)) | 73.2 |
| Type | Pneumatic Piston Pump |
| Weight (lb) | 6.3 |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Fast Lube and Service Centers |
| Compatible Material | ATF, Gear Lube, Oil |
| Construction | Aluminum, NBR, Nickel-Plated Aluminum, Nitrile, Polyurethane, Steel, Zinc-Plated Carbon Steel |
| Cycles Per Gallon | 31 |
| Fluid Inlet Size (in) | 1 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 0.75 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Continuous Cycle Rate (CPM) | 170 |
| Maximum Working Pressure (psi) | 150 |
| Model | Fast-Ball |
| Power Type | Pneumatic |
| Pump Ratio | 1:1 |
| Series | 100 |
| Sound Pressure Level (dB(A)) | 73.2 |
| Type | Pneumatic Piston Pump |
