SaniForce

SaniForce 5:1 Ratio Piston Pump for Sanitary Applications to Transfer Low to Medium Viscosity Fluids

Part Number: 24V324

product image

SaniForce

SaniForce 5:1 Ratio Piston Pump for Sanitary Applications to Transfer Low to Medium Viscosity Fluids

Part Number: 24V324

Still using hoists and chains to unload your drums or bins? Graco's SaniForce Elevator is ideal for small to medium size food and personal care companies who currently unload less than 2 containers per hour. Use with Graco's SaniForce 2:1, 5:1 or 6:1 Piston Pumps to transfer small batches of low to ...

More Info
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Still using hoists and chains to unload your drums or bins? Graco's SaniForce Elevator is ideal for small to medium size food and personal care companies who currently unload less than 2 containers per hour. Use with Graco's SaniForce 2:1, 5:1 or 6:1 Piston Pumps to transfer small batches of low to medium viscosity fluids.

Ideal for small to medium size companies who currently unload containers by scooping or using chains/hoists

  • FDA-compliant
  • Use in sanitary applications to transfer low to medium viscosity fluids
  • Designed to lower pumps into and lift pumps out of drums, bins and totes
  • Articulating arm allows for multiple containers to be unloaded from the same location
  • Mobile and stationary options available

Specifications & Documents

Technical Specifications

Convert to Imperial
Air Inlet Size (in) 0.5
Air Inlet Thread Gender Female
Air Inlet Thread Type NPT
Application Sanitary
Compatible Material Food, Personal Care
Fluid Outlet Size (in) 2
For Use With Food, Personal Care, Pharmaceutical
Includes Cart and Handle, Varied Packings
Material Stainless Steel
Maximum Air Inlet Pressure (psi) 100
Maximum Continuous Cycle Rate (cpm) 60
Maximum Flow Rate (gpm) 14
Maximum Intermittent Cycle Rate (cpm) 60
Maximum Working Pressure (MPa) 2.8
Maximum Working Pressure (psi) 400
Model SaniForce
Portable Portable
Pump Ratio 5:1
Seal Material PTFE, FKM, UHMWPE
Standards Met FDA Compliant Materials, CE
Type Pneumatic Piston Pump
Wetted Material Stainless Steel, Buna-N, UHMWPE, PTFE
Air Inlet Size (in) 0.5
Air Inlet Size (mm) 12.7
Air Inlet Thread Gender Female
Air Inlet Thread Type NPT
Application Sanitary
Compatible Material Food, Personal Care
Fluid Outlet Size (in) 2
Fluid Outlet Size (mm) 50.8
For Use With Food, Personal Care, Pharmaceutical
Includes Cart and Handle, Varied Packings
Material Stainless Steel
Maximum Air Inlet Pressure (bar) 6.9
Maximum Air Inlet Pressure (kPa) 690
Maximum Air Inlet Pressure (psi) 100
Maximum Continuous Cycle Rate (cpm) 60
Maximum Flow Rate (l/min) 53
Maximum Intermittent Cycle Rate (cpm) 60
Maximum Working Pressure (MPa) 2.8
Maximum Working Pressure (bar) 28
Maximum Working Pressure (kPa) 2800
Maximum Working Pressure (psi) 400
Model SaniForce
Portable Portable
Pump Ratio 5:1
Seal Material PTFE, FKM, UHMWPE
Standards Met FDA Compliant Materials, CE
Type Pneumatic Piston Pump
Wetted Material Stainless Steel, Buna-N, UHMWPE, PTFE
