Magnum X5

Magnum X5 Electric TrueAirless Sprayer

Part Number: 262800

product image product image product image product image product image product image product image

Magnum X5

Magnum X5 Electric TrueAirless Sprayer

Part Number: 262800

DIY homeowners and handymen get cost-efficient, high-speed performance with the Magnum X5. This airless sprayer is ideal for painting interior projects and exterior projects, such as decks, siding, fences and small houses. Choose the X5 when you paint on a quarterly basis.
$399.00
USD MSRP
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
DIY homeowners and handymen get cost-efficient, high-speed performance with the Magnum X5. This airless sprayer is ideal for painting interior projects and exterior projects, such as decks, siding, fences and small houses. Choose the X5 when you paint on a quarterly basis.
  • Hardened Stainless Steel Piston Pump - Delivers high pressure power to spray unthinned paints
  • Flexible Suction Tube - Spray directly from 1 or 5 gallon paint containers
  • TrueAirless Spray Tip with SoftSpray Technology - greater control and less overspray with a wide range of coatings
  • Power Flush - Connects to garden hose for fast cleanup
  • Durable Frame - Compact, lightweight and easy to carry
  • Adjustable Pressure - Easy control of paint flow
  • PushPrime - Fast and reliable start-up every time

Specifications & Documents

Technical Specifications

Convert to Metric
Amperage (A) 9.0
Compatible Tip Size (in) 0.009, 0.011, 0.013, 0.015
Construction Aluminum, Brass, Carbide, Fluroelastomer, Leather, Nylon, PVC, Plated Steel, Polypropylene, Stainless Steel, UHMWPE
Engine Size (HP) 0.5
Fluid Outlet Size (in) 1/4
Fluid Outlet Thread Type NPSM
Frame Configuration Stand
Includes SG2 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 25 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide
Inlet Paint Strainer 35 Mesh Stainless Steel Screen
Maximum Flow Rate (GPM) 0.27
Maximum Hose Length (ft) 75
Maximum Tip Size (in) 0.015
Maximum Tip Size 1 Gun (in) 0.015
Maximum Working Pressure (MPa) 20.7
Maximum Working Pressure (psi) 3000
Minimum Generator Power (W) 2500
Model Magnum
Motor Type Universal
Number of Guns 1
Overall Height (in) 17.9
Overall Length (in) 14.5
Overall Width (in) 12.4
Phase 1
Power Rating (HP) 0.5
Power Rating (W) 373
Power Rating (kW) 0.37
Power Source Electric
Pressure Control Type Adjustable
Product Series Project
Pump Rod Type Hardened Stainless Steel
Pump Sleeve Material Stainless Steel
Recommended Annual Usage (gal) 125
Series X5
Type Airless Sprayer
Voltage (V) 120
Weight (lb) 17
Amperage (A) 9.0
Compatible Tip Size (in) 0.009, 0.011, 0.013, 0.015
Construction Aluminum, Brass, Carbide, Fluroelastomer, Leather, Nylon, PVC, Plated Steel, Polypropylene, Stainless Steel, UHMWPE
Fluid Outlet Size (in) 1/4
Fluid Outlet Size (mm) 6.35
Fluid Outlet Thread Type NPSM
Frame Configuration Stand
Includes SG2 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 25 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide
Inlet Paint Strainer 35 Mesh Stainless Steel Screen
Maximum Flow Rate (L/min) 1.0
Maximum Hose Length (m) 23
Maximum Tip Size (in) 0.015
Maximum Tip Size 1 Gun (in) 0.015
Maximum Working Pressure (MPa) 20.7
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20700
Maximum Working Pressure (psi) 3000
Minimum Generator Power (W) 2500
Model Magnum
Motor Type Universal
Number of Guns 1
Overall Height (cm) 45.5
Overall Height (mm) 455
Overall Length (cm) 36.8
Overall Length (mm) 368
Overall Width (cm) 31.5
Overall Width (mm) 315
Phase 1
Power Rating (W) 373
Power Rating (kW) 0.37
Power Source Electric
Pressure Control Type Adjustable
Product Series Project
Pump Rod Type Hardened Stainless Steel
Pump Sleeve Material Stainless Steel
Series X5
Type Airless Sprayer
Voltage (V) 120
Weight (kg) 8

What's Included

Part No. Description Qty Unit
247339 DuraFlex Hose 1/4 in x 25 ft 1 ea
25M568 FLUID, PUMP ARMOR, 8OZ 1 ea
243011 SG2 Metal Spray Gun 1 ea
TRU515 TrueAirless 515 Spray Tip 1 ea
237859 Spray Tip Guard 1 ea

Repair Parts

Part No. Description
15R659 CORD SET, SJT, LIGHTED W/GRIP
243011 SG2 Metal Spray Gun
247339 DuraFlex Hose 1/4 in x 25 ft
16E829 Magnum Control Board Paint Kit for X5 / X7
288706 Magnum Control Board Paint Sprayer Kit for X5 / X7
17L104 Repair Kit, Control Board Replacement, X5, X7
16E842 Magnum X5 Power Cord Paint Sprayer Kit
17L282 Repair Kit, Motor, X5, X7
244266 Pressure Control Switch Replacement Kit
244267 Pro210ES Pressure Switch
235014 Spray Prime/Drain Valve Kit
288716 Inlet Strainer
118899 Repair Kit, Switch, X5, X7
195084 TUBE, DRAIN
197607 TUBE, SUCTION
