Corrosion Resistant Fluid Back Pressure Regulator, 20 bar (300 Max psi), SST, Acetal & PTFE Wetted Parts, 1-1/4 (f) x 1-1/4 (f), with Gauge

Part Number: 224486

Image is for illustrative purposes only.

Corrosion Resistant Fluid Back Pressure Regulator, 20 bar (300 Max psi), SST, Acetal & PTFE Wetted Parts, 1-1/4 (f) x 1-1/4 (f), with Gauge

Part Number: 224486

Control upstream fluid pressure with Graco back pressure regulators. Our back pressure regulators use closed-loop control to maintain the pressure of the system regardless of flow demand. This allows operators to trigger guns, valves and other flow controls without changing the system pressure.
Questions about this product?

Evaluating our products and need advice
before you buy?

Contact Us

Features

Product Brochure
Control upstream fluid pressure with Graco back pressure regulators. Our back pressure regulators use closed-loop control to maintain the pressure of the system regardless of flow demand. This allows operators to trigger guns, valves and other flow controls without changing the system pressure.
  • Stainless steel membrane diaphragm is highly wear-resistant while maintaining accurate responsiveness
  • Low shear diaphragm valve has minimal restriction to reduce material degradation and colour matching issues, especially with metallic paint
  • Stainless steel wetted materials are compatible with catalyst and waterborne materials
  • Large fluid passages to accommodate high-volume flow rates

Specifications & Documents

Technical Specifications

Convert to Imperial
Compatible Material Catalyst, Waterborne
Gauge Port Size (in) 1/4
Gauge Port Type NPT
Includes Gauge
Inlet Size (in) 1-1/2
Inlet Thread Type NPT
Maximum Regulated Pressure (psi) 200
Maximum Viscosity (cP) 1000
Maximum Working Pressure (psi) 300
Minimum Regulated Pressure (MPa) 0.1
Minimum Regulated Pressure (psi) 15
Outlet Size (in) 1-1/2
Outlet Thread Type NPT
Type Back Pressure Regulator
Wetted Material Stainless Steel, Acetal, PTFE
Compatible Material Catalyst, Waterborne
Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type NPT
Includes Gauge
Inlet Size (cm) 3.81
Inlet Size (in) 1-1/2
Inlet Size (mm) 38.1
Inlet Thread Type NPT
Maximum Flow Rate (L/min) 75
Maximum Regulated Pressure (bar) 14
Maximum Regulated Pressure (kPa) 1400
Maximum Regulated Pressure (psi) 200
Maximum Viscosity (cP) 1000
Maximum Working Pressure (bar) 21
Maximum Working Pressure (kPa) 2100
Maximum Working Pressure (psi) 300
Minimum Regulated Pressure (MPa) 0.1
Minimum Regulated Pressure (bar) 1
Minimum Regulated Pressure (kPa) 100
Minimum Regulated Pressure (psi) 15
Outlet Size (cm) 3.81
Outlet Size (in) 1-1/2
Outlet Size (mm) 38.1
Outlet Thread Type NPT
Type Back Pressure Regulator
Wetted Material Stainless Steel, Acetal, PTFE
