390 PC

390 PC Electric Airless Sprayer, Stand

17C310

390 PC

390 PC Electric Airless Sprayer, Stand

17C310

The 390 PC Stand is a solid workhorse built for the professional just “starting out.” Lightweight and portable, it's easy to lift and carry. The 390 PC is the ideal sprayer for residential jobs, and is the best value in small electric sprayers.
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The 390 PC Stand is a solid workhorse built for the professional just “starting out.” Lightweight and portable, it's easy to lift and carry. The 390 PC is the ideal sprayer for residential jobs, and is the best value in small electric sprayers.

The ideal sprayer for residential jobs and the best value in small electric sprayers.

  • Durable Endurance Chromex Piston Pump
    • Lasts 2X longer than the next leading brand
    • Long Life V-Max Blue Packings, Chromex rod and hardened stainless steel cylinder
    • Faster cleaning with the QuikAccess intake valve
  • Advantage Drive
    • The longest lasting drive
    • Hardened steel gears provide extremely quiet operation and a Lifetime Warranty
  • ProConnect One-Part Pump Replacement System
    • Eliminate costly downtime
    • Pump swaps in minutes – no tools, pins or parts to lose
  • Easy Out Pump Filter
    • Easy maintenance & less clogging
    • Exclusive inside-out filtering process ensures a quality finish
  • Rugged Steel Frame
    • Thick chrome over steel withstands rugged environments
    • 4 leg stand provides greater stability
  • Variable Pressure Control
    • Position indicator allows repeatable setting
  • Swivel Inlet Suction Hose
    • Easily reaches paint buckets
  • Contractor FTx Airless Spray Gun
    • Standard features
    • Economic choice for everyday use

Specifications & Documents

Technical Specifications

Convert to Metric
Amperage (A) 13
Compatible Material Acrylics, Enamel, Lacquer, Latex, Stains
Compatible Replacement Pump 17C487
Cycles Per Gallon 700
Engine Size (HP) 0.625
Features Endurance Chromex Pump, Advantage Drive, ProConnect, Easy Out Filter
Fluid Outlet Size (in) 1/4
Fluid Outlet Thread Type NPSM
Frame Configuration Stand
Includes FTx Gun, RAC X LTX 515 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz
Maximum Flow Rate (GPM) 0.47
Maximum Sound Pressure Level (dB(A)) 90
Maximum Tip Size (in) 0.021
Maximum Working Pressure (MPa) 22.8
Maximum Working Pressure (psi) 3300
Minimum Generator Power (W) 3000
Motor Type DC
Number of Guns 1
Outlet Paint Filter 60 Mesh Stainless Steel Screen
Overall Height (in) 18.5
Overall Length (in) 16
Overall Width (in) 14
Phase 1
Power Rating (HP) 0.625
Power Rating (W) 466.1
Power Rating (kW) 0.47
Power Source Electric
Pump Mount Type ProConnect
Pump Rod Type Chromex
Pump Sleeve Material Hardened Steel
Pump Type Endurance
Recommended Annual Usage Up to 50 gallons per week
Series 390 PC
Sound Power Level (dB(A)) 100
Sound Pressure Level (dB(A)) 90
Type Airless Sprayer
Voltage (V) 120
Weight (lb) 34
Wetted Material Acetal, Aluminum, Fluoroelastomer, Leather, Nylon, PTFE, Polyethylene, Stainless Steel, Tungsten Carbide, UHMWPE, Urethane, Zinc-Plated Carbon Steel, Nickel-Plated Carbon Steel
Amperage (A) 13
Compatible Material Acrylics, Enamel, Lacquer, Latex, Stains
Compatible Replacement Pump 17C487
Cycles Per Gallon 700
Engine Size (HP) 0.625
Features Endurance Chromex Pump, Advantage Drive, ProConnect, Easy Out Filter
Fluid Outlet Size (cm) 0.635
Fluid Outlet Size (mm) 6.35
Fluid Outlet Thread Type NPSM
Frame Configuration Stand
Includes FTx Gun, RAC X LTX 515 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz
Maximum Flow Rate (L/min) 1.8
Maximum Sound Pressure Level (dB(A)) 90
Maximum Tip Size (cm) 0.0533
Maximum Tip Size (mm) 0.5334
Maximum Working Pressure (MPa) 22.8
Maximum Working Pressure (bar) 228
Maximum Working Pressure (kPa) 22800
Minimum Generator Power (W) 3000
Motor Type DC
Number of Guns 1
Outlet Paint Filter 60 Mesh Stainless Steel Screen
Overall Height (cm) 47
Overall Height (mm) 470
Overall Length (cm) 40.6
Overall Length (mm) 406
Overall Width (cm) 35.6
Overall Width (mm) 356
Phase 1
Power Rating (HP) 0.625
Power Rating (W) 466.1
Power Rating (kW) 0.47
Power Source Electric
Pump Mount Type ProConnect
Pump Rod Type Chromex
Pump Sleeve Material Hardened Steel
Pump Type Endurance
Recommended Annual Usage Up to 50 gallons per week
Series 390 PC
Sound Power Level (dB(A)) 100
Sound Pressure Level (dB(A)) 90
Type Airless Sprayer
Voltage (V) 120
Weight (kg) 15
Wetted Material Acetal, Aluminum, Fluoroelastomer, Leather, Nylon, PTFE, Polyethylene, Stainless Steel, Tungsten Carbide, UHMWPE, Urethane, Zinc-Plated Carbon Steel, Nickel-Plated Carbon Steel

What's Included

Part No. Description Qty Unit
288430 Contractor FTx Airless Spray Gun, 4 Finger Trigger, RAC X 515 SwitchTip 1 ea
LTX515 RAC X SwitchTip, 515 1 ea
246215 RAC X HandTite Tip Guard 1 ea
240794 BlueMax II Airless Hose, 1/4 in x 50 ft 1 ea
238049 TSL Throat Seal Liquid, 4 oz 1 ea

Repair Parts

Part No. Description
15J743 CORD, POWER, LIGHTED, CART UNIT
119277 FUSE, 16 AMP, TIME LAG, 5 X 20
288430 Contractor FTx Airless Spray Gun, 4 Finger Trigger, RAC X 515 SwitchTip
240794 BlueMax II Airless Hose, 1/4 in x 50 ft
15B071 INSERT, FILTER
24X289 Q KIT, CONTROL, PRESSURE, 3300PSI
117828 KIT, O-RING, PTFE, ENCAPULATED
249052 Q KIT, REPAIR, BOARD CONTROL, 120V
249042 KIT, REPAIR, BRUSH
246382 Easy Out Pump Manifold Filter, Short, 100 mesh
246425 Easy Out Pump Manifold Filter, Short, 30 mesh
246384 Easy Out Pump Manifold Filter, Short, 60 mesh
249051 KIT, REPAIR, LINE, DRAIN
17C794 KIT, REPAIR, ST MOT, 120V, W/FAN
246385 Inlet Strainer, Nylon Cap, 7/8 in
246386 Q KIT, REPAIR, SUCTION SET
235014 Spray Prime/Drain Valve Kit
24W830 KIT,REPLACEMENT,HOSE,CPLD,QD
117559 O-RING
246383 Easy Out Pump Manifold Filter, Short, 200 mesh
