Merkur ES

30:1 Merkur ES Air Assisted Package, 1.5 lpm (0.4 gpm) fluid flow, wall mount, with G40 gun, suction hose and plated steel

Part Number: 24F156

product image
Image is for illustrative purposes only.

Merkur ES

30:1 Merkur ES Air Assisted Package, 1.5 lpm (0.4 gpm) fluid flow, wall mount, with G40 gun, suction hose and plated steel

Part Number: 24F156

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

Questions about this product?

Evaluating our products and need advice
before you buy?

Contact Us

Features

Product Brochure

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

  • Quick flush system requires less than 1 minute to flush
  • 45% less material needed to fill the system than leading competitors
  • Delivers a superior, consistent spray finish
  • Low profile spray package makes it easy to transport
  • Easily set and monitor air control. Also fitted with an integrated carrying handle for transport
  • Air motor provides consistent finishes with smooth, rapid changeover
  • Suction hose and strainer leave less material in the supply container
  • Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

Specifications & Documents

Technical Specifications

Convert to Imperial
Convertible Non-Convertible
Fluid Outlet Size (in) 1/4
Fluid Outlet Thread Type NPSM
Gun Included 1
Gun Model G40
Gun Type Air-Assisted
Gun technology Air-assisted
Hose Inlet Diameter (in) 1/8
Includes G40 Gun, Suction Hose, Wall Mount
Maximum Flow Rate (GPM) 0.40
Maximum Hose Length (ft) 25
Maximum Tip Size (in) 0.019
Maximum Working Pressure (MPa) 20.7
Maximum Working Pressure (psi) 3000
Model Merkur
Motor Type Pneumatic
Mount Type Wall Mount
Number of Guns 1
Power Source Air
Pressure Type High Pressure
Product Type Spray Package
Pump Ratio 30:1
Pump Type Pneumatic piston pump
Series ES
Spray Type Air-Assisted
Type Air-Assisted Airless Sprayer
Weight (lb) 20
Wetted Material Stainless Steel, Carbon Steel, Nickel-Plated Carbon Steel, Tungsten Carbide, PTFE, Acetal, Leather, UHMWPE
Convertible Non-Convertible
Fluid Outlet Size (in) 1/4
Fluid Outlet Size (mm) 6.35
Fluid Outlet Thread Type NPSM
Gun Included 1
Gun Model G40
Gun Type Air-Assisted
Gun technology Air-assisted
Hose Inlet Diameter (cm) 0.3175
Hose Inlet Diameter (in) 1/8
Hose Inlet Diameter (mm) 3
Includes G40 Gun, Suction Hose, Wall Mount
Maximum Flow Rate (L/min) 1.5
Maximum Hose Length (m) 7.5
Maximum Tip Size (in) 0.019
Maximum Working Pressure (MPa) 20.7
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20700
Maximum Working Pressure (psi) 3000
Model Merkur
Motor Type Pneumatic
Mount Type Wall Mount
Number of Guns 1
Power Source Air
Pressure Type High Pressure
Product Type Spray Package
Pump Ratio 30:1
Pump Type Pneumatic piston pump
Series ES
Spray Type Air-Assisted
Type Air-Assisted Airless Sprayer
Weight (kg) 9
Wetted Material Stainless Steel, Carbon Steel, Nickel-Plated Carbon Steel, Tungsten Carbide, PTFE, Acetal, Leather, UHMWPE
