ExactaBlend AGP  Advanced Glazing Proportioner

For sealant and adhesive applications in curtainwall and insulating glass

Where to BuyRequest Info
IMG_0058

Superior mixing and ratio assurance for the glass industry

The Graco ExactaBlend AGP (Advanced Glazing Proportioner) provides on-ratio dispensing of two-component sealants and adhesives for curtainwall, insulating glass and other applications. The variable ratio ExactaBlend AGP offers advanced technologies at an affordable price.

Product quality through accurate & on-ratio mixing

  • Eliminate guesswork and human error
  • Auto shutdown if off-ratio conditions occur
  • No soft spots and consistent curing

Less waste for more profits

  • Automatically monitors and adjusts the catalyst flow rate
  • Save time, labor and material expenses
  • Green light indicator confirms on-ratio dispense of two-part material

Quick start-up & easy to use

  • Easy setup - simply enter the ratio setting
  • Easy to operate digital controls to change ratio settings
  • Eliminate guesswork when setting the ratio
  • No mechanical linkages and rocker arms to adjust
Contact Our Experts

Your privacy is very important to Graco. We will not sell your information to other companies. However, to best serve your needs, your information may be shared with Graco's distributor partners. For details, view our Privacy Policy.

  • Easy set-up and operation
  • Green light indicates on-ratio dispensing
  • Automatic shut down when off-ratio conditions occur
  • Optimal mixing and on-ratio proportioning capabilities for quality assurance
  • Quick and easy base purge reduces material waste
  • Optional data download provides reports on ratio, flow rate and material usage



ExactaBlend AGP Advanced Glazing Proportioner
Maximum fluid working pressure : MD2 or Ultra-lite with flexible hose mixer Installed
3000 psi
21 MPa, 207 bar
Maximum fluid working pressure :Ultra-lite with Tri-core mixer Installed
4000 psi
28 MPa, 276 bar
Incoming Air pressure required: Startup pressures and displacement per cycle may vary based on suction condition, discharge head, air pressure, and fluid type.
80-100 psi
0.6-0.7 MPa, 6.0-7.0 bar
Maximum operating temperature
120°F
50°C
Voltage range
90-264 VAC 50/60 Hz 1 phase
90-264 VAC 50/60 Hz 1 phase
Maximum amperage
4
4
Sound pressure: Sound pressure measured 3.3 feet (1 meter) from equipment.
82 dB(A)
82 dB(A)
Wetted parts: Refer to specific component manual for more details.
Zinc-plated carbon steel, aluminum ram plate, nitrile rubber wipers, chrome, stainless steel, UHMW polyethylene, PTFE, nylon, Buna-N
Zinc-plated carbon steel, aluminum ram plate, nitrile rubber wipers, chrome, stainless steel, UHMW polyethylene, PTFE, nylon, Buna-N
Inlet/Outlet Sizes
Fluid outlet base
1/2 npt (f)
1/2 npt (f)
Fluid outlet catalyst
1/4 npt (f)
1/4 npt (f)
Air inlet size
3/4 npt (f)
3/4 npt (f)
Weight
All models
865 lb.
392 kg
