Stainless Steel High Pressure Fluid Gauge, 0-1000 psi (0-68 bar) pressure range
Part Number: 105770
Image is for illustrative purposes only.
Stainless Steel High Pressure Fluid Gauge, 0-1000 psi (0-68 bar) pressure range
Part Number: 105770
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Stainless Steel High Pressure Fluid Gauges
- Corrosion Resistant
- 2.5 in (63 mm) diameter dial
- 1/4 in NPT(M) connection
- Bottom mount
- Shatterproof glass
- Liquid filled to reduce indicator pulsation
Specifications & Documents
Technical Specifications
Convert to Metric| Dial Diameter (in) | 2.5 |
|---|---|
| Inlet Size (in) | 1/4 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Material | Stainless Steel |
| Maximum Working Pressure (MPa) | 6.9 |
| Maximum Working Pressure (psi) | 1000 |
| Type | Pressure Gauge |
| Dial Diameter (cm) | 6 |
| Dial Diameter (in) | 2.5 |
| Dial Diameter (mm) | 64 |
| Inlet Size (cm) | 0.635 |
| Inlet Size (in) | 1/4 |
| Inlet Size (mm) | 6.35 |
| Inlet Thread Gender | Male |
| Inlet Thread Type | NPT |
| Material | Stainless Steel |
| Maximum Working Pressure (MPa) | 6.9 |
| Maximum Working Pressure (bar) | 69 |
| Maximum Working Pressure (kPa) | 6900 |
| Type | Pressure Gauge |
