AirPro Auto

AirPro Automatic Air Spray Gun, conventional, 0.030 in (0.8 mm) nozzle for general metal applications

24A747

AirPro Auto

AirPro Automatic Air Spray Gun, conventional, 0.030 in (0.8 mm) nozzle for general metal applications

24A747

Graco's automatic applicators are lightweight, compact and provide consistent spray patterns for a high quality finish.
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
Graco's automatic applicators are lightweight, compact and provide consistent spray patterns for a high quality finish.
  • General metal gun models are designed to optimize spray performance
  • Fluid control knob for precision fluid adjustment
  • Stainless steel construction handles the toughest coatings, from acid to waterborne
  • Indexing aircap provides fast and accurate positioning in either the vertical or horizontal position
  • Lightweight and compact rounded gun design

Specifications & Documents

Technical Specifications

Convert to Metric
Application Metal
Applicator Type Automatic
Bleed Type Bleeder
Body Material Metal
Compatible Material Adhesives, Ceramics, Mortar, High Solids, Sealants, Solventborne, Stains, Waterborne
Component Type Single Component
Feed Type Pressure Feed
Fluid Orifice Size (in) 0.030
Gun Activation Automatic
Gun Type Conventional Gun
Gun Weight (lb) 1.5
Includes Air Cap With Pin, Air Cap Without Pin, Piston Cap, Manifolds, Nozzle, Needle Tip, Needle Assembly, Needle/Nozzle Kit
Maximum Air Inlet Pressure (MPa) 0.7
Maximum Air Inlet Pressure (psi) 100
Maximum Air Pressure (MPa) 0.7
Maximum Air Pressure (psi) 100
Maximum Flow Rate @ PSI (oz/min) 10
Maximum Fluid Pressure (MPa) 0.7
Maximum Fluid Pressure (psi) 100
Maximum Fluid Temperature (°F) 120
Minimum Flow Rate @ PSI (oz/min) 4
Model AirPro
Overall Height (in) 1
Overall Length (in) 5.3
Overall Width (in) 1
Purge Method Air
Series Auto
Spray Pattern Round
Spray Type Air Spray
Technology Type Conventional
Type Spray Gun
Application Metal
Applicator Type Automatic
Bleed Type Bleeder
Body Material Metal
Compatible Material Adhesives, Ceramics, Mortar, High Solids, Sealants, Solventborne, Stains, Waterborne
Component Type Single Component
Feed Type Pressure Feed
Fluid Orifice Size (cm) 0.08
Fluid Orifice Size (mm) 0.8
Gun Activation Automatic
Gun Type Conventional Gun
Gun Weight (g) 680
Gun Weight (kg) 0.68
Includes Air Cap With Pin, Air Cap Without Pin, Piston Cap, Manifolds, Nozzle, Needle Tip, Needle Assembly, Needle/Nozzle Kit
Maximum Air Inlet Pressure (MPa) 0.7
Maximum Air Inlet Pressure (bar) 7
Maximum Air Inlet Pressure (kPa) 700
Maximum Air Pressure (MPa) 0.7
Maximum Air Pressure (bar) 7
Maximum Air Pressure (kPa) 700
Maximum Fluid Pressure (MPa) 0.7
Maximum Fluid Pressure (bar) 7
Maximum Fluid Pressure (kPa) 700
Maximum Fluid Temperature (°C) 49
Model AirPro
Overall Height (cm) 3
Overall Height (mm) 25
Overall Length (cm) 13
Overall Length (mm) 135
Overall Width (cm) 3.8
Overall Width (mm) 25
Purge Method Air
Series Auto
Spray Pattern Round
Spray Type Air Spray
Technology Type Conventional
Type Spray Gun

CAD Drawings


Repair Parts

Part No. Description
24A683 Needle Assembly for AirPro Automatic Guns with 0.030 inch (0.8 mm) Nozzle, General Metal
288183 Needle Tip Kit (5-pack, 3 grooves) for AirPro Guns with 0.030 inch (0.8 mm) Nozzle
289062 Nozzle Kit for AirPro Guns with 0.030 inch (0.8 mm) Nozzle, General Metal or Automotive
24B544 Air Cap, with locating pin, for AirPro Automatic Conventional Guns, General Metal
289773 Air Cap Kit for AirPro Conventional Guns with 0.020-0.070 in (0.5-1.8 mm) Nozzle
24A687 Needle/Nozzle Kit for AirPro Automatic Guns with 0.030 inch (0.8 mm) Nozzle, General Metal
192453 Piston Cap for Manual and Automatic Spray Guns
289045 Air Cap Kit for AirPro Complaint Guns with 0.110 inch (2.8 mm) Nozzle, General Metal
289067 Nozzle Kit for AirPro Guns with 0.110 inch (2.8 mm) Nozzle, General Metal
24B670 Stainless Steel Air Cap Kit for AirPro Automatic Complaint, 0.020-0.070 inch (0.5-1.8 mm) Nozzle, General Metal
289563 HVLP Pressure Verification Kit, General Metal
24B671 Stainless Steel Air Cap Kit for AirPro Automatic Conventional, 0.020-0.070 in (0.5-1.8 mm) Nozzle, General Metal
24B672 Stainless Steel Air Cap Kit for AirPro Automatic Conventional, 0.070 inch (1.8 mm) Nozzle, General Metal
289566 HVLP Pressure Verification Kit, Wood
288862 Air Cap Kit for AirPro Conventional Guns with 0.020-0.040 inch (0.5-1.0 mm) Nozzle, Wood
289066 Nozzle Kit for AirPro Guns with 0.086 inch (2.2 mm) Nozzle, General Metal
289004 Needle Tip Kit (5-pack) for AirPro Guns with 0.086 inch (2.2 mm) Nozzle
289350 Needle Tip Kit (5-pack, 1 groove), for AirPro Guns with 0.020 inch (0.5 mm) Nozzle
288863 Air Cap Kit for AirPro Compliant Guns with 0.020-0.040 inch (0.5-1.0 mm) Nozzle, Wood
24B669 Stainless Steel Air Cap Kit for AirPro Automatic HVLP, 0.020-0.070 inch (0.5-1.8 mm) Nozzle, General Metal
24B667 Stainless Steel Air Cap Kit, with locating pin, for AirPro Automatic Conventional, 0.020-0.070 in (0.5-1.8 mm) Nozzle, General Metal
289070 Air Cap Kit for AirPro HVLP Guns with 0.086 inch (2.2 mm) Nozzle, General Metal
288907 Nozzle Kit for AirPro Guns with 0.020 inch (0.5 mm) Nozzle, Wood
289007 Needle Tip Kit (5-pack) for AirPro Gun with 0.110 inch (2.8 mm) Nozzle
289568 HVLP Pressure Verification Kit, High Wear 0.059 in (1.5 mm)
289069 Air Cap Kit for AirPro Conventional Guns with 0.110 inch (2.8 mm) Nozzle, General Metal
289043 Air Cap Kit for AirPro HVLP Guns with 0.110 inch (2.8 mm) Nozzle, General Metal
289044 Air Cap Kit for AirPro Complaint Guns with 0.086 inch (2.2 mm) Nozzle, General Metal
288864 Air Cap Kit for AirPro HVLP Guns with 0.020-0.040 inch (0.5-1.0 mm) Nozzle, Wood
24B668 Stainless Steel Air Cap Kit, with locating pin, for AirPro Automatic Conventional, 0.070 inch (1.8 mm) Nozzle, General Metal
289569 HVLP Pressure Verification Kit, High Wear 0.070 in (1.8 mm)
289068 Air Cap Kit for AirPro Conventional Guns with 0.086 inch (2.2 mm) Nozzle, General Metal
24B665 Stainless Steel Air Cap Kit, with locating pin, for AirPro Automatic HVLP, 0.020-0.070 inch (0.5-1.8 mm) Nozzle, General Metal
24B666 Stainless Steel Air Cap Kit, with locating pin, for AirPro Automatic Complaint, 0.020-0.070 inch (0.5-1.8 mm) Nozzle, General Metal

Recommended Accessories

Service Videos

See how to disassemble and reassemble an AirPro Auto Air Spray Gun so that the automatic applicator continues to work well.
