AirPro EFX

AirPro EFX Auto Air Spray Gun, Direct Connect, HVLP, 0.028 inch (0.7 mm) Nozzle, SST Tip, Lock Ring Fluid Adjust Knob

24B881

19130_hvlp_DC_LockRing 18574 18576

AirPro EFX

AirPro EFX Auto Air Spray Gun, Direct Connect, HVLP, 0.028 inch (0.7 mm) Nozzle, SST Tip, Lock Ring Fluid Adjust Knob

24B881

The AirPro EFX air spray automatic guns are among the lightest and most compact guns in their class. With no internal air shutoff mechanism, the AirPro EFX delivers increased reliability and precision fluid flow. The modest size and weight of this gun make it an excellent choice for fixed, reciproca... More Info
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The AirPro EFX air spray automatic guns are among the lightest and most compact guns in their class. With no internal air shutoff mechanism, the AirPro EFX delivers increased reliability and precision fluid flow. The modest size and weight of this gun make it an excellent choice for fixed, reciprocating and robotic applications.
  • Aircaps and nozzles deliver superior, precision spray performance
  • Precision fluid adjustment with a micrometer-telescoping knob
  • High wear components designed for abrasive materials
  • Excellent fluid flow rate stability and repeatability

Specifications

Technical Specifications

Convert to Metric
Applicator Type Automatic
Bleed Type Bleeder
Body Material Plastic
Compatible Material Ceramics, Enamel, Fast-Set, High Solids, Solventborne, Waterborne
Component Type Single Component
Feed Type Pressure Feed
Fluid Adjustment Knob Lock Ring
Fluid Orifice Size (in) 0.028
Gun Activation Automatic
Gun Type HVLP Gun
Gun Weight (lb) 0.6
Includes Air Cap with Pin, Needle/Nozzle Kit, Fluid Adjustment Knob
Maximum Air Inlet Pressure (MPa) 0.7
Maximum Air Inlet Pressure (psi) 100
Maximum Air Pressure (MPa) 0.7
Maximum Air Pressure (psi) 100
Maximum Flow Rate @ PSI (oz/min) 3.4
Maximum Fluid Pressure (MPa) 0.7
Maximum Fluid Pressure (psi) 100
Maximum Fluid Temperature (°F) 120
Minimum Flow Rate @ PSI (oz/min) 0.3
Model AirPro
Needle Tip Material Stainless Steel
Overall Height (in) 1
Overall Length (in) 4.1
Overall Width (in) 1
Purge Method Air
Series EFX
Spray Pattern Round
Spray Type Air Spray
Technology Type HVLP
Type Spray Gun
Applicator Type Automatic
Bleed Type Bleeder
Body Material Plastic
Compatible Material Ceramics, Enamel, Fast-Set, High Solids, Solventborne, Waterborne
Component Type Single Component
Feed Type Pressure Feed
Fluid Adjustment Knob Lock Ring
Fluid Orifice Size (cm) 0.07
Fluid Orifice Size (mm) 0.7
Gun Activation Automatic
Gun Type HVLP Gun
Gun Weight (kg) 0.27
Includes Air Cap with Pin, Needle/Nozzle Kit, Fluid Adjustment Knob
Maximum Air Inlet Pressure (MPa) 0.7
Maximum Air Inlet Pressure (bar) 7
Maximum Air Inlet Pressure (kPa) 700
Maximum Air Pressure (MPa) 0.7
Maximum Air Pressure (bar) 7
Maximum Air Pressure (kPa) 700
Maximum Fluid Pressure (MPa) 0.7
Maximum Fluid Pressure (bar) 7
Maximum Fluid Pressure (kPa) 700
Maximum Fluid Temperature (°C) 49
Model AirPro
Needle Tip Material Stainless Steel
Overall Height (cm) 2.2
Overall Height (mm) 25
Overall Length (cm) 10
Overall Length (mm) 104
Overall Width (cm) 3.5
Overall Width (mm) 25
Purge Method Air
Series EFX
Spray Pattern Round
Spray Type Air Spray
Technology Type HVLP
Type Spray Gun
