MSA-10™ Pneumatic Pump
Part Number: 562854
Image is for illustrative purposes only.
MSA-10™ Pneumatic Pump
Part Number: 562854
MSA Series products are used together with main lubrication supply lines where the pump is fed directly with no additional reservoir required. No reservoir makes the MSA Series ideal for locations that are difficult to reach or undesirable to enter. Use the MSA-10 for standard applications.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
MSA Series products are used together with main lubrication supply lines where the pump is fed directly with no additional reservoir required. No reservoir makes the MSA Series ideal for locations that are difficult to reach or undesirable to enter. Use the MSA-10 for standard applications.
- Ideal for applications where space is a premium
- Handles high pressure lubricant feed of direct line intake
- Used with or without a reservoir for the ultimate flexibility
- Lubriquip part number 140-000-111
Specifications & Documents
Technical Specifications
Convert to Metric| Air Inlet Size (in) | 1/4 |
|---|---|
| Air Inlet Thread Type | NPSF |
| Application | In-Plant Machinery |
| Compatible Material | Oil, Grease |
| Includes | Repair Parts Kit |
| Material | Steel |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Cycle Rate (CPM) | 60 |
| Maximum Fluid Output Pressure (psi) | 1450 |
| Maximum Working Pressure (MPa) | 20.7 |
| Maximum Working Pressure (psi) | 3000 |
| Minimum Air Inlet Pressure (psi) | 40 |
| Power Type | Pneumatic |
| Type | Pneumatic Piston Pump |
| Air Inlet Size (in) | 1/4 |
| Air Inlet Size (mm) | 6.35 |
| Air Inlet Thread Type | NPSF |
| Application | In-Plant Machinery |
| Compatible Material | Oil, Grease |
| Includes | Repair Parts Kit |
| Material | Steel |
| Maximum Air Inlet Pressure (bar) | 10.34 |
| Maximum Air Inlet Pressure (kPa) | 1034 |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Cycle Rate (CPM) | 60 |
| Maximum Fluid Output Pressure (bar) | 100 |
| Maximum Fluid Output Pressure (psi) | 1450 |
| Maximum Working Pressure (MPa) | 20.7 |
| Maximum Working Pressure (bar) | 206.8 |
| Maximum Working Pressure (kPa) | 20680 |
| Maximum Working Pressure (psi) | 3000 |
| Minimum Air Inlet Pressure (psi) | 40 |
| Power Type | Pneumatic |
| Type | Pneumatic Piston Pump |
