PH Pump

PH Pump™ with 5 lb. (2.27 kg) Plastic Cylindrical Grease Reservoir

Part Number: 564379

product image
Image is for illustrative purposes only.

PH Pump

PH Pump™ with 5 lb. (2.27 kg) Plastic Cylindrical Grease Reservoir

Part Number: 564379

Modular pump and reservoir design plus built-in features enable the PH Manual Pump to be customized for a wide range of applications. The PH Manual Pump permits increased standardization with resultant economies in spare parts stocking and greater employee familiarity with plant or job site lubricat...

More Info
Product is Discontinued

Replacement Product Not Available


Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure

Modular pump and reservoir design plus built-in features enable the PH Manual Pump to be customized for a wide range of applications. The PH Manual Pump permits increased standardization with resultant economies in spare parts stocking and greater employee familiarity with plant or job site lubrication systems. This pump is sturdily built with aluminum and steel components to meet the high standards of performance and quality you expect from Graco products. It is a compact, space-saving unit.

  • Built-in volume indicator provides easy verification that lubricant is being delivered to the system and that divider valves are completing lube cycles.
  • Interchangeable reservoirs make it convenient to expand or contract the lube distribution system, to switch from oil to grease or from grease to oil – without replacing the entire system.
  • Wide applicability is provided by an optional two- or four outlet valve that mounts under the pump outlet. This valve allows the pump to serve up to four different systems or to supply one or two separate manual reversing systems.
  • Single-acting positive displacement pump design minimizes the number of moving and wearing parts for extended pump life and reduced maintenance.
  • Built-in automatic relief valve protects system components from over-pressure.
  • Built-in outlet check valve prevents back pressure from damaging pump and minimizes chance for contaminants to get into the pump or the lube supply.
  • 3,000 psi (207 bar) pressure gauge provides a fast check on system status.
  • Lubriquip part number 521-800-130

Specifications & Documents

Technical Specifications

Convert to Metric
Application In-Plant Machinery
Compatible Material Grease
Includes Pump, Reservoir, Gauge, Fittings, Hardware
Maximum Working Pressure (psi) 3000
Model PH Pump
Power Type Manual
Reservoir Material Plastic
Reservoir Shape Cylindrical
Reservoir Size (lb) 5
Reservoir Weight Capacity (lb) 5
Type Hand Pump
Application In-Plant Machinery
Compatible Material Grease
Includes Pump, Reservoir, Gauge, Fittings, Hardware
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20700
Maximum Working Pressure (psi) 3000
Model PH Pump
Power Type Manual
Reservoir Material Plastic
Reservoir Shape Cylindrical
Reservoir Weight Capacity (kg) 0
Type Hand Pump
