QUANTM h120
QUANTM h120, 2" FG SST Electric Diaphragm Pump, 200-240 V, FEP AL Center, SS Seat, PT Ball, PS Diaphragm
Part Number: HE120-0006
QUANTM h120
QUANTM h120, 2" FG SST Electric Diaphragm Pump, 200-240 V, FEP AL Center, SS Seat, PT Ball, PS Diaphragm
Part Number: HE120-0006
QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, ...
More Info
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.
Graco food-grade pumps are our most popular series for general food transfer. With their all-stainless-steel construction and 125 Ra surface finish, the groundbreaking new QUANTM food-grade electric pumps are certified to handle a wide range of food and beverage products and meet certification requirements for some personal care applications as well. From dressings, sauces, oils, syrups to soaps, creams and solvents, QUANTM electric food-grade pumps are a workhorse for almost any hygienic food-grade application. The powerful new electric motor delivers up to 8x more continuous torque at low speeds than conventional motors and the fast, easy plug-and-play installation allows you to easily replace existing pumps without additional investment or infrastructure rework.
- Revolutionary Design
- Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
- Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
- Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
- Quiet operation reduces plant noise and improves employee safety and health
- Smart pump control provides more accurate flow set points and built-in I/O
- Efficient Electric Motor
- FEP coated aluminum electric drive
- 240 VAC 1φ motor with 15 ft cord and NEMA L15-20 plug
- Non-hazardous
- Materials of Construction
- 125 Ra surface finish 316 stainless steel fluid section with tri-clamp center port
- Internal components include 316L stainless steel seat, PTFE ball, PTFE/Santoprene 2-Piece diaphragm and PTFE manifold o-ring
- EN 2.1 material certification
Specifications & Documents
Technical Specifications
Convert to Metric| Application | Food, Beverage, Personal Care, Pharmaceutical |
|---|---|
| Ball Material | PTFE |
| Center Section Material | FEP Coated Aluminum |
| Connection Type | Tri-Clamp |
| Construction | 316L Stainless Steel, 316 Stainless Steel, PTFE, PTFE/Santoprene 2-Piece |
| Cord Length (ft) | 15 |
| Diaphragm Material | PTFE/Santoprene 2-Piece |
| Fluid Inlet Size (in) | 2-1/2 |
| Fluid Inlet Thread Type | Tri-Clamp |
| Fluid Outlet Size (in) | 2-1/2 |
| Fluid Outlet Thread Type | Tri-Clamp |
| Fluid Passage Size (in) | 2 |
| Fluid Passage Size (mm) | 51 |
| Fluid Section | 316 Stainless Steel, End Port, Tri-Clamp |
| Fluid Section Material | 316 Stainless Steel |
| Hazardous Location Approval | None |
| Manifold Configuration | End Port |
| Manifold O-Ring Material | PTFE |
| Material Certification | EN 1024:2004 Type 2.1 (Standard) |
| Maximum Ambient Temperature (°F) | 104 |
| Maximum Amperage (A) | 7.5 |
| Maximum Flow Rate (GPM) | 120 |
| Maximum Fluid Operating Temperature (°C) | 82 |
| Maximum Fluid Operating Temperature (°F) | 180 |
| Maximum Fluid Pressure (psi) | 60 |
| Maximum Solid Size (in) | 0.25 |
| Minimum Fluid Operating Temperature (°C) | -40 |
| Minimum Fluid Operating Temperature (°F) | -40 |
| Model | QUANTM |
| Motor Type | Electric Drive |
| Overall Height (in) | 25.95 |
| Seat Material | 316L Stainless Steel |
| Series | h120 |
| Standards Met | FDA Compliant Materials |
| Surface Finish | 125 Ra |
| Tri-Clamp Connection Size | 2.5 in. |
| Type | Electric Diaphragm Pump |
| Voltage (V ac) | 240 VAC 3Ph |
| Weight (lb) | 170 |
| Application | Food, Beverage, Personal Care, Pharmaceutical |
| Ball Material | PTFE |
| Center Section Material | FEP Coated Aluminum |
| Connection Type | Tri-Clamp |
| Construction | 316L Stainless Steel, 316 Stainless Steel, PTFE, PTFE/Santoprene 2-Piece |
| Cord Length (m) | 4.57 |
| Diaphragm Material | PTFE/Santoprene 2-Piece |
| Fluid Inlet Size (in) | 2-1/2 |
| Fluid Inlet Size (mm) | 64 |
| Fluid Inlet Thread Type | Tri-Clamp |
| Fluid Outlet Size (in) | 2-1/2 |
| Fluid Outlet Size (mm) | 64 |
| Fluid Outlet Thread Type | Tri-Clamp |
| Fluid Passage Size (in) | 2 |
| Fluid Passage Size (mm) | 51 |
| Fluid Section | 316 Stainless Steel, End Port, Tri-Clamp |
| Fluid Section Material | 316 Stainless Steel |
| Hazardous Location Approval | None |
| Manifold Configuration | End Port |
| Manifold O-Ring Material | PTFE |
| Material Certification | EN 1024:2004 Type 2.1 (Standard) |
| Maximum Ambient Temperature (°C) | 40 |
| Maximum Amperage (A) | 7.5 |
| Maximum Flow Rate (L/min) | 454 |
| Maximum Fluid Operating Temperature (°C) | 82 |
| Maximum Fluid Operating Temperature (°F) | 180 |
| Maximum Fluid Pressure (bar) | 4.14 |
| Maximum Fluid Pressure (kPa) | 414 |
| Maximum Fluid Pressure (psi) | 60 |
| Maximum Solid Size (mm) | 6.35 |
| Minimum Fluid Operating Temperature (°C) | -40 |
| Minimum Fluid Operating Temperature (°F) | -40 |
| Model | QUANTM |
| Motor Type | Electric Drive |
| Seat Material | 316L Stainless Steel |
| Series | h120 |
| Standards Met | FDA Compliant Materials |
| Surface Finish | 125 Ra |
| Tri-Clamp Connection Size | 2.5 in. |
| Type | Electric Diaphragm Pump |
| Voltage (V ac) | 240 VAC 3Ph |
