Dura-Flo D60
41:1 Ratio 20 L D60 Supply Unit
Part Number: GDB54F
Dura-Flo D60
41:1 Ratio 20 L D60 Supply Unit
Part Number: GDB54F
Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials
- 60 liter (16-gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
- Graco D60 - Provides higher down-force and 60-liter pail capacity
- Industry-first controls give you immediate and important information at the touch of a button
- Quick placement of pail
- Platen wipers can be replaced in seconds
- Pump's quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
- High-quality, durable parts reduce maintenance time, maximize uptime
Specifications & Documents
Technical Specifications
Convert to Metric| Ambient/Warm Melt/Hot Melt | Ambient |
|---|---|
| Application | Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill |
| Construction | Stainless Steel, Tungsten Carbide, PTFE, Glass-Filled PTFE, Stainless Steel, Polyurethane, PTFE Coated Nitrile, Polyethylene, Nitrile |
| Container Type | Pail |
| Material Container Volume (gal) | 5.3 |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Height (ft) | 2.92 |
| Maximum Height (in) | 35 |
| Maximum Operating Temperature (°F) | 120 |
| Minimum Height (ft) | 4.92 |
| Minimum Height (in) | 59 |
| Model | Dura-Flo |
| Overall Depth (in) | 18 |
| Overall Width (in) | 28 |
| Power Type | Pneumatic |
| Pump Ratio | 41:1 |
| Pump Type | Double Ball |
| Ram Material | Carbon Steel |
| Series | D60 |
| Type | Supply Unit |
| Ambient/Warm Melt/Hot Melt | Ambient |
| Application | Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill |
| Construction | Stainless Steel, Tungsten Carbide, PTFE, Glass-Filled PTFE, Stainless Steel, Polyurethane, PTFE Coated Nitrile, Polyethylene, Nitrile |
| Container Type | Pail |
| Material Container Volume (l) | 20 |
| Maximum Air Inlet Pressure (bar) | 10.34 |
| Maximum Air Inlet Pressure (kPa) | 1034 |
| Maximum Air Inlet Pressure (kg/cm²) | 10.55 |
| Maximum Air Inlet Pressure (psi) | 150 |
| Maximum Height (cm) | 88.9 |
| Maximum Height (m) | 0.9 |
| Maximum Height (mm) | 889 |
| Maximum Operating Temperature (°C) | 49 |
| Minimum Height (cm) | 149.86 |
| Minimum Height (m) | 1.5 |
| Minimum Height (mm) | 1498.6 |
| Model | Dura-Flo |
| Overall Depth (cm) | 45.72 |
| Overall Depth (mm) | 457.2 |
| Overall Width (cm) | 71.12 |
| Overall Width (mm) | 711.2 |
| Power Type | Pneumatic |
| Pump Ratio | 41:1 |
| Pump Type | Double Ball |
| Ram Material | Carbon Steel |
| Series | D60 |
| Type | Supply Unit |
