E-Flo 4-Ball
E-Flo 4-Ball Electric Circulation Pump, 230/400V 3 HP ATEX, 1500cc, Open Wet Cup, Ultralife Rod/Cylinder, Tri-Clamp, Stand
EP31H1
E-Flo 4-Ball
E-Flo 4-Ball Electric Circulation Pump, 230/400V 3 HP ATEX, 1500cc, Open Wet Cup, Ultralife Rod/Cylinder, Tri-Clamp, Stand
EP31H1
The dual lower of the E-Flo electric circulating pump minimizes pressure changes at the outlet of the pump. Online maintenance simplifies repair and reduces downtime. Accomplish remote monitoring of performance via computer or PLC for a higher degree of control.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The dual lower of the E-Flo electric circulating pump minimizes pressure changes at the outlet of the pump. Online maintenance simplifies repair and reduces downtime. Accomplish remote monitoring of performance via computer or PLC for a higher degree of control.
- Open wet cup has improved durability and includes Ultralife ceramic coating
- 3 times more efficient than pneumatics
- Process control and feedback
- Slow smooth change overs
- Low noise
- Sealed 4-ball version is also available
Specifications & Documents
Technical Specifications
Convert to Metric| Application | Circulation |
|---|---|
| Compatible Material | Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC |
| Fluid Inlet Size (in) | 2 |
| Fluid Outlet Size (in) | 2 |
| Fluid Section Type | Open Wet Cup |
| Input Voltage (V ac) | 230/400 |
| Material | Stainless Steel |
| Maximum Continuous Cycle Rate (CPM) | 12 |
| Maximum Flow Rate (GPM) | 8.1 |
| Maximum Input Amperage (A) | 20/15 |
| Maximum Operating Temperature (°F) | 104 |
| Maximum Speed (RPM) | 1800 |
| Maximum Working Pressure (MPa) | 2.9 |
| Maximum Working Pressure (psi) | 425 |
| Minimum Operating Temperature (°F) | 32 |
| Motor Type | AC |
| Portable | Non-Portable |
| Power Rating (HP) | 3 |
| Standards Met | CE, ATEX |
| Type | Electric Piston Pump |
| Wetted Material | Stainless Steel |
| Application | Circulation |
| Compatible Material | Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC |
| Fluid Inlet Size (cm) | 5.08 |
| Fluid Inlet Size (mm) | 50.8 |
| Fluid Outlet Size (cm) | 5.08 |
| Fluid Outlet Size (mm) | 50.8 |
| Fluid Section Type | Open Wet Cup |
| Input Voltage (V ac) | 230/400 |
| Material | Stainless Steel |
| Maximum Continuous Cycle Rate (CPM) | 12 |
| Maximum Flow Rate (L/min) | 30.66 |
| Maximum Input Amperage (A) | 20/15 |
| Maximum Operating Temperature (°C) | 40 |
| Maximum Speed (RPM) | 1800 |
| Maximum Working Pressure (MPa) | 2.9 |
| Maximum Working Pressure (bar) | 29 |
| Maximum Working Pressure (kPa) | 2900 |
| Minimum Operating Temperature (°C) | 0 |
| Motor Type | AC |
| Portable | Non-Portable |
| Power Rating (HP) | 3 |
| Standards Met | CE, ATEX |
| Type | Electric Piston Pump |
| Wetted Material | Stainless Steel |
Product Manuals
311876N, 4-Ball Lower Retrofit Connection Kits, Instructions, Parts List, English
(1 MB)
(English Only)
Certifications
Repair Parts
| Part No. | Description |
|---|---|
| 289552 | Electric Motor Kit, 230/400V, 3 Phase, 3 HP Motor, 1500 rpm for E-Flo 1500 Pumps |
| 17K664 | Open Wet Cup Pump Lower, 750 cc, Stainless Steel, Ultralife Rod & Cylinder, Tri-Clamp Fittings |
| 15H874 | Slider Cylinder Rebuild Kit |
| 15H877 | TDC Sensor Kit |
| 15H880 | Motor coupler kit- to install electric motors on E-Flo® 4-Ball Piston Pumps |
| 15H882 | Slider Bearing Kit |
| 15H886 | Gear Reducer Replacement Kit for E-Flo 2000/3000/4000 Pumps |
| 15J639 | Inlet/Outlet Fitting, converts 1-1/2 tri-clamp to 2 tri-clamp |
| 24E453 | Motor Mounting Kit for IEC 112M/B5 and 100L/B5 Frame Electric Motors, includes motor adapter plate |
| 289550 | Gear Reducer Replacement Kit for E-Flo 1500 Pumps |
| 24J305 | Sensor Circuit Option Kit for E-Flo Pumps (Series D and later) |
| 15H873 | Drive Linkage Rebuild Kit |
| 15J378 | Crank Arm Cover Kit |
| 247341 | Slider Cylinder Collector Kit |
| 15H871 | Gear Reducer Seal Kit |
| 15K012 | Air pressure to the BPR Control Kit |
| 15H878 | Manifold Gasket Kit |
| 15J422 | Inlet/Outlet Fitting, converts 1-1/2 tri-clamp to 1-1/2 npt |
| 15J423 | Inlet/Outlet Fitting, converts 2 tri-clamp to 2 npt |
| 24H372 | ACS Module for E-Flo Circulation Pumps |
| 15H883 | Crank Arm Kit |
| 15H885 | Ethernet Interface Kit |
| 15J926 | Output Shaft Seal Tool Kit |
| 255216 | Wrist Pin Replacement Kit |
| 16C487 | Coupler Kit for NEMA 182-184 TC Frame 3 or 5 HP motors. Includes 2.25 in. (57.2 mm) key |
